Hanging Movable Wood Folding Soundproof Acoustic Room Divider for Banquet Hall
Acoustic room dividers details
Acoustic room divider is also called movable acoustic wall. It can separate the space into several small spaces or turn several small spaces into big space according to your different need. Morever, it’s flexible sliding combination bring you a special experience.
1. Seven characters and functions:
(1) hang track on the ceiling, not the floor;
(2) heat insulation and fireproof
(3) stable and safe
(4) energy-efficientcy
(5) elegant appearance
(6) collection convenient
(7) widely used in different places
2. Usage:
Type 65 is suitable to use at 2m-4.2m height space.
Type 85 is suitable to use at 2m-6m height space.
Type 100 is suitable to use at 2m-8m height space.
3. Each panel load-bearing weight: 225kgs/ 450kgs/ 650kgs
4. Sound insulation coefficient:
Type 65 highest sound insulation coefficient can be reach is 32db.
Type 85 the highest sound insulation coefficient can be reach is 48db.
Type 100 the highest sound insulation coefficient can be reach is 53db.
Acoustic room dividers features
1. Acoustic room dividers can separate the space speedy and conveniently.
2. Muti-function: sound insulation,heat insulation,fireproof function.
3. Top hung system without the need for a floor track.
4. The acoustic room dividers panel is made from high density aluminum frame, special made rubber, excellent sound insulation cotton and finish surface, etc.
5. Around the acoustic room dividers panel, there is sound insulation rubber, it can help to insulate the sound entering.
6. Easy element adjustment after installation.
7. Track system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers.
8. Surface panel shall be of 9mm or 12mm MDF with acoustic treatment to the required level.
Technical information
| Series | BG65 | BG80 / BG85 | BG100 & BG125 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with
double rubber seals | Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied
operating handle | Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or
double open in two panel | Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc.(Customized) |
