Sliding Aluminium Doors Movable Acsoustic Folding Partition Wall For Office Multi Color

Name: Sliding Aluminium Doors Movable Acsoustic Folding Partition Wall For Office Multi Color
Brand: BUNGE
Price: 98 USD

Sliding Aluminium Doors Movable Acsoustic Folding Partition Wall For Office Multi Color Manufactures

Brand Name : BUNGE

Model Number : Series 65 mm acoustic partition walls

Certification : ISO9001

Place of Origin : China,Guangzhou

MOQ : 10 square meters

Price : 98 / 32 dollar per square meter

Payment Terms : D/A, D/P, L/C, T/T, Western Union, MoneyGram

Supply Ability : 5000 square meters per month

Delivery Time : Shipped in 10 days after payment, based on the quantity.

Packaging Details : Carton package, MDF batten on four section sides ,foam board on both front face.

Height : 4 m

Width : 500-1200 mm

Thickness : 65 mm

Surface : Melamine

Application : Office,conference room

Color : Multi color

Contact Now

Movable Soundproof Wall Office Acsoustic Folding Partitions

Specification:

Movable partition also is also called movable acoustic wall. It can separate the space into several small spaces or turn several small spaces into big space according to your different need. Moreover, it’s flexible sliding combination bring you a special experience.

Feature:

1. No need floor suspension: There is no track on the floor, just install the track on the ceiling;
2. Stable and safe: It is stable and reliable after being cut off, and it is not easy to swing;
3. Soundproof and environmental protection: sound insulation effect is good, the maximum sound insulation coefficient can reach 53dB;
4. Insulation and energy conservation: excellent insulation performance, according to different seating rates, the large space is divided into small spaces to reduce the air conditioning power consumption;
5.High-efficiency fire prevention: The use of high-efficiency fireproof materials, good fireproof performance.

Sliding Aluminium Doors Movable Acsoustic Folding Partition Wall For Office Multi Color
Advantage:

Long-term use: with more economy and higher decorative, beautiful and safe, will not scratch the skin.
Cost savings: installation does not affect the construction of smallpox and the ground.
Various forms: optional with a variety of occasions partition wall, can be customized according to customer requirements.
Easy combination: in the re-assembly can make full use of building materials.
Material environmental protection: selection of high-quality melamine particleboard, sound insulation and sealing a good variety of accessories a variety of options.

Technical information:

TYPE	BG65	BG85	BG100
Panel suspension	Top hung only
Track system	Single or twin point
Panel thickness	65 mm	85 mm	100 mm
Panel height	Up to 4000mm,heights greater than 3000mm refer to our technical dept.	Up to 6000mm, heights greater than 6000mm refer to our technical dept. Inset passing doors above 2400mm. Full height passing door up to 3000mm high document ‘M’ disabled doors optional.
Max height	4000mm	6000mm	18000mm
Panel width	500 - 1200mm 1' 5/8" -- 4'	500 - 1200mm 1' 5/8" -- 4'	500 - 1200mm 1' 5/8" -- 4'
Frame	Aluminum	Aluminum	Aluminum
Surface material	9mm	9mm	12mm
Fire safety	Optional class I	Optional class I	Optional class I
Vertical profiles	Aluminum, anodized with sealing profiles, painter optional	Aluminum, anodized with sealing profiles, painter optional	Aluminum, anodized with sealing profiles, painter optional
Retractable seals	Aluminum, black with double rubber seals	Aluminum, black with double rubber seals	Aluminum, black with double rubber seals
Operation of seals	Manual, with supplied operating handle
Locking	Optional lock to passing doors
Passing doors	Single open in one panel or double open in two panel
Sound insulation	32-38dB Rw	36-45dB Rw	42-55dB Rw
Weight	Approx 22-35kg/sq M	Approx 25-40kg/sq M	Approx 30-48kg/sq M

Sliding Aluminium Doors Movable Acsoustic Folding Partition Wall For Office Multi Color

Aluminium accessories detail:
Panels:The Panels will be made from 12mm MDF boards and shall be 100mm thick and 1230mm maximum width, made to the appropriate acoustic rating and structural backing and mounted in full perimeter extruded aluminium frames with interlocking corner construction .The panel faces shall be finished with selected material.
Seals: vinyl seal of butane rubber will be used as top and bottom and as well as closure seals for the operable wall system.Retractable seal drop will be 23mm.

Product Tags:

acoustic operable partitions

movable acoustic partition walls

Sliding Aluminium Doors Movable Acsoustic Folding Partition Wall For Office Multi Color Images
